GA102

Product Overview

Trento Entry Doors made of 14-Guage steel with 1/2 in. to 3/4 in. wrought iron for design work. Our standard door jamb is 6 in. the door sheet thickness is 1 in. or 2 in. x 6 in. wide around the wrought iron opening. The weight of Our Iron Door entryways are supported by barrel hinges with ball bearings and grease fittings. All doors will be Prehung, frames are equipped with mounting flanges to secure the frame and lag bolt could be used. Weather stripping around the door and glass frame. All doors are pre-bored with 2-3/4 in. backset, 2-1/8 in. borings and 5-1/2 in. center to center. Most welding is performed from the inside in order not to alter smooth finish line.

Door frames are squared and leveled before the door hinges are positioned and welded thereby ensuring a smooth operation door frames are squared to less than 1/4 in. tolerance
A 1/2 in. flat bar is welded onto the bottom of each frame to maintain installation, 1/2 in. flat bar is also used to secure the door to the floor
Each entry door includes double-pane tempered insulated matt glass-panels that open independently from the doors, this feature allows for ventilation, ease of cleaning glass and the option locked while the homeowner is talking to the visiting party
All doors are fully insulated with thermal injected foam in the door, window frame and in the door sheet, no lockset included
